Rhamnose
Rhamnose is a 6-carbon deoxy-sugar (a hexose). A deoxy-sugar is a sugar that has had a hydroxyl group replaced with a hydrogen atom. In lignocellulosic biomass rhamnose occurs in some hemicelluloses and is a major constituent of the pectins (along with uronic acids).
Click here to place an order for determining Rhamnose.
Analysis Packages for Rhamnose
The Celignis Analysis Package(s) that determine this constituent are listed below:
P7 Lignocellulosic Sugars |
---|
Total Sugars, Glucose, Xylose, Mannose, Arabinose, Galactose, Rhamnose |
P9 Lignocellulosic Sugars and Lignin |
---|
Total Sugars, Glucose, Xylose, Mannose, Arabinose, Galactose, Rhamnose, Lignin (Klason), Lignin (Acid Soluble), Acid Insoluble Residue, Ash (Acid Insoluble) |
P12 Sugars in Solvent Extract |
---|
Glucose, Xylose, Fructose, Sucrose, Mannose, Arabinose, Galactose, Rhamnose, Xylitol, Sorbitol, Trehalose, Mannitol, Arabinitol, Glycerol, Raffinose |
P21 Sugars in Solution |
---|
Total Sugars, Glucose, Xylose, Mannose, Arabinose, Galactose, Rhamnose, Xylitol, Sucrose, Fructose, Sorbitol, Trehalose, Mannitol, Cellobiose, Glycerol |
P61 Sugars in Bio-Oil Water Extract |
---|
Levoglucosan, Cellobiosan, Mannosan, Galactosan, Glucose, Xylose, Mannose, Arabinose, Galactose, Rhamnose, Fucose, Sucrose, Cellobiose, Total Sugars |
P71 Seaweed Carbohydrates |
---|
Fucose, Mannitol, Glucose, Xylose, Mannose, Arabinose, Galactose, Rhamnose, Total Sugars, Glucuronic Acid, Galacturonic Acid, Mannuronic Acid, Guluronic Acid, Iduronic Acid |
P200 Algae Carbohydrates |
---|
Total Sugars, Glucose, Xylose, Galactose, Arabinose, Mannose, Rhamnose |
Analytical Procedure for Rhamnose
Step 1: Acid Hydrolysis of the Sample
When this Method is the first step in the Analysis Package, the acid hydrolysis takes place on the biomass sample with no prior extraction carried out at Celignis. If previous Steps involving the extraction of the sample have take place then the extracted material is used for the acid hydrolysis.
In the case where three different types of extracted material exist (water-extracted, ethanol-extracted, and water- then ethanol-extracted) then the sample that has undergone both water and ethanol extraction is typically used for acid hydrolysis, unless otherwise requested by the customer.
The following steps are involved in the acid hydrolysis of a sample.
1. The moisture content of the sample is determined, in duplicate.
2. Approximately 300 mg (with the exact weight noted) of the sample is added to a pressure tube.
3. 3.00 mL of 72% H2SO4 is added by means of an automatic titrator, the weight of the acid added is noted.
4. The sample is mixed thoroughly with the acid using a glass rod, care is taken that no sample stays adherent to the sides of the tube, but instead stays in contact with the acid.
5. The tube is transferred to a water bath that is maintained at 30 degrees celcius.
6. Steps 2-5 are repeated for the duplicate sample.
7. Every 10 minutes the glass rod for each pressure tube is stirred so that the acid reaches all parts of the sample and complete hydrolysis occurs. This is a crucial step.
8. Exactly one hour after it is placed in the water bath the pressure tube is removed and placed on a scales and 84 mL of water added (with the weight of the added water recorded). Any acid/sample on the rod is removed from the rod at this point using this water.
9. A lid is screwed on the tube and the tube is inverted several times to ensure thorough mixing of the acid.
10. Two sugar recovery solution (SRS) pressure tubes are prepared in order to monitor the sugar-loss associated with the second-stage-hydrolysis. This involves the following steps:
(a) 348 microlitres of 72% H2SO4 is added to a test tube containing a solution containing a known weight (approximately 10 g) of a sugar standard. This standard should be of a similar sugar composition to that expected of the samples being analysed. The acid and sugar solution are thoroughly mixed.
(b) The sugar-acid mixture is transferred to a pressure tube which is then sealed.
11. All SRS and sample pressure tubes are placed in an autoclave which is run at 121 degrees celcius for 60 minutes.
12. After the temperature in the autoclave drops to under 80C the tubes are removed and are left (closed) in the lab until they reach room temperature.
13. The hydrolysates are then filtered (using vacuum suction) through filter crucibles of known weight and the resulting filtrate is stored.
14. Any residual solids are washed out from the tube using deionised water until all the Acid Insoluble Residue resides on the filter crucible.
In the case where three different types of extracted material exist (water-extracted, ethanol-extracted, and water- then ethanol-extracted) then the sample that has undergone both water and ethanol extraction is typically used for acid hydrolysis, unless otherwise requested by the customer.
The following steps are involved in the acid hydrolysis of a sample.
1. The moisture content of the sample is determined, in duplicate.
2. Approximately 300 mg (with the exact weight noted) of the sample is added to a pressure tube.
3. 3.00 mL of 72% H2SO4 is added by means of an automatic titrator, the weight of the acid added is noted.
4. The sample is mixed thoroughly with the acid using a glass rod, care is taken that no sample stays adherent to the sides of the tube, but instead stays in contact with the acid.
5. The tube is transferred to a water bath that is maintained at 30 degrees celcius.
6. Steps 2-5 are repeated for the duplicate sample.
7. Every 10 minutes the glass rod for each pressure tube is stirred so that the acid reaches all parts of the sample and complete hydrolysis occurs. This is a crucial step.
8. Exactly one hour after it is placed in the water bath the pressure tube is removed and placed on a scales and 84 mL of water added (with the weight of the added water recorded). Any acid/sample on the rod is removed from the rod at this point using this water.
9. A lid is screwed on the tube and the tube is inverted several times to ensure thorough mixing of the acid.
10. Two sugar recovery solution (SRS) pressure tubes are prepared in order to monitor the sugar-loss associated with the second-stage-hydrolysis. This involves the following steps:
(a) 348 microlitres of 72% H2SO4 is added to a test tube containing a solution containing a known weight (approximately 10 g) of a sugar standard. This standard should be of a similar sugar composition to that expected of the samples being analysed. The acid and sugar solution are thoroughly mixed.
(b) The sugar-acid mixture is transferred to a pressure tube which is then sealed.
11. All SRS and sample pressure tubes are placed in an autoclave which is run at 121 degrees celcius for 60 minutes.
12. After the temperature in the autoclave drops to under 80C the tubes are removed and are left (closed) in the lab until they reach room temperature.
13. The hydrolysates are then filtered (using vacuum suction) through filter crucibles of known weight and the resulting filtrate is stored.
14. Any residual solids are washed out from the tube using deionised water until all the Acid Insoluble Residue resides on the filter crucible.
Step 2: Hydrolysate Dilution and Storage
Following the Acid Hydrolysis Step, the hydrolysate (the filtrate from the vacuum filtration) is diluted by a factor of 5 using a fucose-in-water solution. Fucose is the internal standard that is used in the chromatographic analysis of the hydrolysate. Following this dilution the samples are either immediately put on the chromatography system or stored in a freezer for future analysis.
Step 3: Chromatographic Analysis of the Hydrolysate
Equipment Used for Rhamnose Analysis
NIR Spectrophotometers We have several FOSS XDS NIR devices. These have solid content modules, that can allow for samples of a heterogenous particle to be analysed, and liquid modules that allow liquids to be analysed via transmittance spectroscopy. |
Ion Chromatography A Dionex ICS-3000 system that is equipmed with electrochemical, conductivity, and ultraviolet-visible detectors. |
Autoclave An autoclave is used in the protocols for the determination of the lignin and structural sugars (cellulosic and hemicellulosic) contents of samples. |
NIR Model
Rhamnose Global 1
This model has been built from a global dataset comprising a wide variety of biomass samples. Click here for a list of the types of samples that were used to build this model.
The samples were air-dried and then ground-down to a particle size of less than 850 microns prior to NIR analysis.
Model Statistics
Min. Value (%) | 0.02 |
---|---|
Max. Value (%) | 1.56 |
Calibration Samples | 451 |
Validation Samples | 154 |
R2 (Validation) | 0.861 |
RMSEP (%) | 0.096 |
Bias (%) | 0.005 |
SEP (%) | 0.096 |
RPD | 2.682 |
RER | 14.534 |
